Astam Valve - Feature
The cylindrical shape body gives full scope to its ability for high pressure-temperaturepiping in case of considering thermal contraction and expansion. Metal-to-Metal seat is applied to the body of Ductile Iron, Cast steel,…etc. And SS316overlay, SS410 overlay, Monel overlay, Stellite #6 overlay are available and can bespecified to meet the fluid applications.
Kings Instruments 7200 Series - Acrylic Tube Flowmeter
• Low-Cost, Low-Maintenance Applications
• Machined Acrylic Meter; 127mm Scale
• In-Line 3/8” – 2” NPT Connections
• 1 – 200 GPM Water; 4 – 245 SCFM Air
• Machined Acrylic Meter; 127mm Scale
• In-Line 3/8” – 2” NPT Connections
• 1 – 200 GPM Water; 4 – 245 SCFM Air
Kings Instruments 7100 Series - Stainless Steel Tube Flowmeter
• Low-Flow, High- Pressure Applications
• SS Construction; 60mm Scale
• Magnetically Coupled Dial Type Display
• 0.16 - 25 GPH Water; 1 - 120 SCFH Air
• SS Construction; 60mm Scale
• Magnetically Coupled Dial Type Display
• 0.16 - 25 GPH Water; 1 - 120 SCFH Air
Kings Instruments 7310 Series - Polysulfone Tube Flowmeter
• Economical Polysulfone Meter in SS Case
• 316L SS, Hastelloy®C, or Teflon® Internals
• 127mm Detachable, Direct Reading Scale
• 0.5 – 150 GPM Water; 4 – 330 SCFM Air
• 316L SS, Hastelloy®C, or Teflon® Internals
• 127mm Detachable, Direct Reading Scale
• 0.5 – 150 GPM Water; 4 – 330 SCFM Air
Kings Instruments 7330 Series - Polysulfone Tube Flowmeter
• Union Ends for Ease of Installation
• Polysulfone Meter with Alarm Options
• 316L SS, Hastelloy®C, or Teflon® Internals
• 127mm Detachable, Direct Reading Scale
• 0.5 – 150 GPM Water
• Polysulfone Meter with Alarm Options
• 316L SS, Hastelloy®C, or Teflon® Internals
• 127mm Detachable, Direct Reading Scale
• 0.5 – 150 GPM Water
Kings Instruments 7430 Series - Glass Tube Flowmeters
• Low-Flow and Gas Purge Applications
• Borosilicate Glass Metering Tube
• Stainless Steel Frame with Horizontal Connections
• 65 mm or 150mm Scale
• 0.72 – 1,800 cc/min Water; 66 – 70,000 cc/min Air
• Borosilicate Glass Metering Tube
• Stainless Steel Frame with Horizontal Connections
• 65 mm or 150mm Scale
• 0.72 – 1,800 cc/min Water; 66 – 70,000 cc/min Air
Kings Instruments 7450 Series - Glass Tube Flowmeter
• Borosilicate Kinglass Meter with Side Plate
• Material Options for Higher Chemical Resistance
• Optional Control Valve; Panel - Mountable
• 75mm, 150mm Detachable, Direct Reading Scales
• 0.48 – 7.4 GPM Water; 2 – 20 SCFM Air
• Material Options for Higher Chemical Resistance
• Optional Control Valve; Panel - Mountable
• 75mm, 150mm Detachable, Direct Reading Scales
• 0.48 – 7.4 GPM Water; 2 – 20 SCFM Air
Kings Instruments 7459 Series - Glass Tube Flowmeter
• High-Accuracy, Borosilicate Kinglass Meter
• Side Plate Construction with Polycarbonate Shield
• 316L SS, In-Line FNPT Connections
• 250mm Detachable, Direct Reading Scale
• 0.22 – 100 GPM Water; 0.9 – 350 SCFM Air
• Side Plate Construction with Polycarbonate Shield
• 316L SS, In-Line FNPT Connections
• 250mm Detachable, Direct Reading Scale
• 0.22 – 100 GPM Water; 0.9 – 350 SCFM Air
Kings Instruments 7460 Series - Glass Tube Flowmeter
• Economical Borosilicate Kinglass Meter
• 316L SS Case and Internals
• In-Line FNPT Connections
• 75mm Detachable, Direct Reading Scales
• 0.5 – 25 GPM Water; 2 – 14 SCFM Air
• 316L SS Case and Internals
• In-Line FNPT Connections
• 75mm Detachable, Direct Reading Scales
• 0.5 – 25 GPM Water; 2 – 14 SCFM Air
Kings Instruments 7470 Series - Glass Tube Flowmeter
• Versatile Borosilicate Kinglass Meter
• 304 SS Case and Internals
• NPT or Flange Connections, In-Line or Horizontal
• 127mm Detachable, Direct Reading Scales
• 0.25 – 116 GPM Water; 1 – 245 SCFM Air
• 304 SS Case and Internals
• NPT or Flange Connections, In-Line or Horizontal
• 127mm Detachable, Direct Reading Scales
• 0.25 – 116 GPM Water; 1 – 245 SCFM Air
Kings Instruments 7480 Series - Glass Tube Flowmeter
• Installation Versatility and Excellent Value
• NPT or Flange Connections, In-Line or Horizontal
• Borosilicate Kinglass Meter with SS Case and Internals
• 250mm Detachable, Direct Reading Scales
• 0.22 – 132 GPM Water; 0.9 – 350 SCFM Air
• NPT or Flange Connections, In-Line or Horizontal
• Borosilicate Kinglass Meter with SS Case and Internals
• 250mm Detachable, Direct Reading Scales
• 0.22 – 132 GPM Water; 0.9 – 350 SCFM Air
Kings Instruments 7510 & 7511 Series - Acrylic Tube Flowmeter
• Precision Machined Acrylic Meter
• Block Type, Panel Mountable
• In-Line Connections
• 50mm, 75mm, 100mm, 127mm, 250mm scales
• 0.12 – 20 GPM Water; 0.04 – 60 SCFM Air
• Block Type, Panel Mountable
• In-Line Connections
• 50mm, 75mm, 100mm, 127mm, 250mm scales
• 0.12 – 20 GPM Water; 0.04 – 60 SCFM Air
